MT Series Transparent LED Display
MT Series Transparent LED Display
Key Features
- Ultra High Transparency
- Super Lightweight Design
- High Brightness for Daylight Viewing
- Asymmetric Pixel Pitch for Visual Depth
- Modular, Quick Lock Installation
MT Series Transparent LED Display
Transparent LED Display redefines digital signage by delivering brilliant, high brightness LED content while maintaining significant architectural transparency. Ideal for glass facades, retail windows , and corporate lobbies, this display offers an unobtrusive digital canvas that preserves natural light and viewing visibility.
Rapid Setup and Ultra Light Design
The highly modular cabinet design is crafted from aluminum and weighs as little as 10Kg/m2. This makes it easy to handle, transport, and install via standard hanging methods.
- Min. Weight
Architectural Integration & High Visibility
Achieve stunning visual effects without blocking ambient light or the view through glass facades. With transparency up to >75% and high brightness exceeding 3500 cd/m2, content is vivid day and night.
- Up to >75% Transparency
Durable, High Performance Content
Engineered with a high refresh rate of >1920Hz and robust SMD1921 LEDs, the MT Series delivers smooth video content and boasts an exceptional 100,000 hour lifespan, ensuring long-term reliability.
- 100,000 Hour Life Span
End to End Project Support
From initial planning to long-term maintenance, our teams ensure your display solution is a success. We provide complete project assurance, beginning with Seamless Installation and backed by dedicated Technical Support throughout the operational lifecycle. This commitment extends through robust After-sales Service for maximum longevity, coupled with specialized Content & ROI Guidance to help maximize your investment’s visibility and success.
- After sales Service
- Seamless Installation
- Technical Support
- Content & ROI Guidance
Capture Every Detail: The MT Series in Professional Environments
Technical Specifications
Compare the MT Series: Find Your Ideal Transparency & Pitch Ratio
| Parameter | MT2.6-5.2 | MT3.9-7.8 |
|---|---|---|
| Model Number | MT2.6-5.2 | MT3.9-7.8 |
| Cabinet Size (W x H) | 1000mm×1000mm or 1000mm×500mm | 1000mm×1000mm or 1000mm×500mm |
| Cabinet Resolution (W x H) | 384×192 or 384×96 | 256×128 or 256×64 |
| Cabinet Weight | 12Kg/m² | 10Kg/m² |
| Cabinet Material | Aluminum (Alu) | Aluminum (Alu) |
| Pixel Pitch (V x H) | 2.6mm×5.2mm | 3.9mm×7.8mm |
| Pixel Density | 73,728 dots/m² | 32,768 dots/m² |
| LED Type | SMD1921 | SMD1921 |
| Transparency | >50% | >75% |
| Brightness | >3500 cd/m² | >3500 cd/m² |
| Viewing Angle (H/V) | 150∘/130∘ | 150∘/130∘ |
| Color | 16.7M | 16.7M |
| Contrast Ratio | 5000:1−10000:1 | 5000:1−10000:1 |
| Color Temperature | 3000−15000K | 3000−15000K |
| Refresh Frequency | >1920Hz | >1920Hz |
| Max. Power Consumption | 600w/m² | 600w/m² |
| Ave. Power Consumption | 180w/m² | 180w/m² |
| Input Voltage | AC 100−240V 50/60HZ | AC 100−240V 50/60HZ |
| Life Span | 100,000 Hours | 100,000 Hours |
| Maintenance Method | Front Maintenance | Front Maintenance |
| Hanging Supportive | Yes | Yes |
| IP Rating | Indoor (IP33) | Indoor (IP33) |
Custom Project Solutions
Discuss your specialized LED project today.
Get a Custom Quote in 24 Hours
Connect with our technical LED specialists to precisely map your vision, ensuring the perfect pixel pitch, brightness, and structural fit for your project.
